FRONT RUNNER Nissan Navara D23 DC (2014-Current) Drawer Kit
Make storing and organizing gear and valuables a no-brainer. These 2 lockable drawers with fitted deck and faceplates have been designed specifically for the Nissan Navara D23 DC. Hide contents from prying eyes while creating more usable and easily accessible storage space in your vehicle. Engineered tough for both on and off-road travel.
1 x Drawer Base Unit (SSDR010)1 x Drawer System Wing Set1 x Nissan Navara D23 DC Deck Completion Set (SSDS503)2 x Push to close latch with 2 keys per lock3 x Accessory channels6 x Eye Nuts for accessory channelsInstallation Hardware includes 4 turnbuckles to secure the unitFitting Instruction
Aluminum - Accessory Channels Sub FrameBlack powder coated steel - Drawer Bins FrameCarpet Laminated plywood - Top Deck Deck Set
1483mm (58.4'') L x 1550mm (61'') W x 300mm (11.8) HOverall Drawer Dimensions:1230mm (48.4'') L x 1080mm (42.5'') W x 300mm (11.8) HInterior Drawer Dimensions:Left Hand Drawer:1156mm (45.5'') L x 445mm (17.5'') W x 208mm (8.2'') HRight Hand Drawer:1156mm (45.5'') L x 445mm (17.5'') W x 208mm (8.2'') HWeight:94.68kg (208.7lbs)Load Rating:113Kg (250lbs) per Drawer
FRONT RUNNER Nissan Navara D23 DC (2014-Current) Drawer Kit Features
- This drawer kit has 2 lockable drawers, 2 keys per lock, 3 tie-down rails, 6 tie-down rings, deck completion set, face completion set, brackets, all necessary installation hardware, and detailed fitment instructions.
- 113kg / 250 lb per drawer load carrying capacity.
- High-strength bearing slides allow each drawer to extend nearly 100% from the anchored base.
- This drawer kit can be easily installed in minutes by attaching the supplied carabiners and turnbuckles to the vehicle’s existing mounting points and the drawer mounting brackets.
- Removing the drawers is just as easy.
- Provides peace of mind and security by locking away important travel items such as computers, smartphones and camera gear.
- The flat deck incorporates three cargo attachment channels and 6 Tie Down Rings / Eye Nuts For Drawer System - by Front Runner.
- Customize your own storage configurations.
- Stack and secure luggage, Wolf Pack - by Front Runner, Cub Pack - by Front Runner, aluminum boxes and other storage containers to the top deck using Stratchits - by Front Runner or other straps.
- The deck above the drawers can also be used to mount Front Runner Cargo / Fridge Slides.
- The left side Faceplate has 4 pre-cut knock-outs for adding electrical panel socket inserts.
- The right side faceplate has 2 pre-cut knock-outs for water fittings for use with Stainless Steel Water Tank for Pickup Drawer System / 52l - by Front Runner (sold separately).
- The side decks are easily removable creating storage space between the drawers and vehicle for a variety of items such as tools, jumper cables, tow ropes, diving snorkels, masks, fins, kindling, barbeque skewers, etc.
- To create a removable box option, use Cub Pack - by Front Runner or Flat Pack - by Front Runner inside the drawers.
- The Cub Pack - by Front Runner or Flat Pack - by Front Runner can be used to further organize and easily move gear in and out of a vehicle.
- To create compartments within the drawers, add the optional steel Drawer Dividers - by Front Runner.
- Drawer Dividers help organize and stop excessive movement of gear and supplies.
- Sold in pairs, these drawers can accommodate up to 4 dividers per drawer.
- The deck is covered with a durable, UV resistant, nylon pile, black carpet.
- The nylon carpet surface creates resiliency for securing cargo while insulating against noise and vibration.
- Finished with the same durable black powder coating as the Front Runner Slimline II Roof Rack and other Front Runner products.
- This storage system is designed for interior use with a canopy, camper shell, or other style bed / load bed cover.
- All Front Runner Storage Systems are backed by a 2 year warranty.
- *Please Note: Cub Packs and Flatpack Storage Boxes are not included when purchasing this Drawer System and are sold separately.Note: The Deck Completion Set for this drawer kit requires modification when installed with an existing plastic load liner.
